SW Series Bellows-sealed Valves

SWSS-TS4-2
Bellows-sealed Valve, Body: 316SS, MWP: 1,000psig, Bellows: 316L, Stem Tip: Stellited Spherical, Conn.: 1/4in. x 1/4in. Tube Socket Weld, Orifice:4.1mm, Cv:0.36, Green Al T-bar Handle
SWSS-ML6-2
Bellows-sealed Valve, Body: 316SS, MWP: 1,000psig, Bellows: 316L, Stem Tip: Stellited Spherical, Conn.: 6mm x 6mm Tube OD, 2-Ferrule, Orifice:4.1mm, Cv:0.36, Green Al T-bar Handle
SWSS-FL8-5
Bellows-sealed Valve, Body: 316SS, MWP: 1,000psig, Bellows: 316L, Stem Tip: Stellited Spherical, Conn.: 1/2in. x 1/2in. Tube OD, 2-Ferrule, Orifice:7.6mm, Cv:1.2, Green Al T-bar Handle
SWSS-FL6-3
Bellows-sealed Valve, Body: 316SS, MWP: 1,000psig, Bellows: 316L, Stem Tip: Stellited Spherical, Conn.: 3/8in. x 3/8in. Tube OD, 2-Ferrule, Orifice:6.6mm, Cv:0.8, Green Al T-bar Handle
SWSS-FL4-2
Bellows-sealed Valve, Body: 316SS, MWP: 1,000psig, Bellows: 316L, Stem Tip: Stellited Spherical, Conn.: 1/4in. x 1/4in. Tube OD, 2-Ferrule, Orifice:4.1mm, Cv:0.36, Green Al T-bar Handle
SWSS-ML12-5
Bellows-sealed Valve, Body: 316SS, MWP: 1,000psig, Bellows: 316L, Stem Tip: Stellited Spherical, Conn.: 12mm x 12mm Tube OD, 2-Ferrule, Orifice:7.6mm, Cv:1.2, Green Al T-bar Handle
SWSS-FFR4-2
Bellows-sealed Valve, Body: 316SS, MWP: 1,000psig, Bellows: 316L, Stem Tip: Stellited Spherical, Conn.: 1/4in. x 1/4in. Female FR (Metal Gasket Face Seal), Orifice:4.1mm, Cv:0.36, Green Al T-bar Handle
SWSS-TS6-4
SWSS-TS6-4
SWSS-TS8-5
SWSS-TS8-5
