NG Series Needle Valves

NGSS-FL4-7-Y
Needle valve in 316 SS, conn.1/4"OD - Pmax: 207 bar - Tmax: 232°C - PTFE seal - with nut for panel mounting
4 PCE available

Livraison en 3 jours ouvrés.
NGSS-UMB14-8
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 14mm x 14mm BW Bulge Nipple with Union Nut, Oriffice: 6.4mm, Cv:0.7, Black Knob Handle
Out of stock

Délai de livraison sur demande (contact).
NGSS-ML14-8
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 14mm x 14mm Tube OD, 2-Ferrule, Oriffice: 6.4mm, Cv:0.7, Black Knob Handle
Out of stock

Livraison en 20 jours ouvrés.
NGSS-FL8-8
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 1/2in. x 1/2in. Tube OD, 2-Ferrule,Orifice:6.4mm, Cv:0.7, Black Knob Handle
Out of stock

Livraison en 10 jours ouvrés.
NGSS-NS8-8
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 1/2in. x 1/2in. (M)NPT, Orifice:6.4mm, Cv:0.7, Black Knob Handle
Out of stock

Délai de livraison sur demande (contact).
NGSS-NS4-7
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 1/4in. x 1/4in. (M)NPT, Orifice:4mm, Cv:0.35, Black Knob Handle
Out of stock

Livraison en 10 jours ouvrés.
NGSS-ML3-5
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 3mm x 3mm Tube OD, 2-Ferrule, Orifice:2mm, Cv:0.09, Black Knob Handle
Out of stock

Livraison en 20 jours ouvrés.
NGSS-ML6-7-Y
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 6mm x 6mm Tube OD, 2-Ferrule, Orifice:4mm, Cv:0.35, Black Knob Handle with panel mounting nut
10 PCE available

Livraison en 3 jours ouvrés.
NGSS-ML8-7
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 8mm x 8mm Tube OD, 2-Ferrule, Orifice:4mm, Cv:0.35, Black Knob Handle
4 PCE available

Livraison en 3 jours ouvrés.
NGSS-ML12-8
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 12mm x 12mm Tube OD, 2-Ferrule, Oriffice: 6.4mm, Cv:0.7, Black Knob Handle
3 PCE available

Livraison en 3 jours ouvrés.
NGSS-ML10-8
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 10mm x 10mm Tube OD, 2-Ferrule, Oriffice: 6.4mm, Cv:0.7, Black Knob Handle
Out of stock

Livraison en 10 jours ouvrés.
NGSS-FNS8-9
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 1/2in. x 1/2in. (F)NPT, Orifice:10mm, Cv:1.8, Black Al T-bar Handle
1 PCE available

Livraison en 3 jours ouvrés.
NGSS-FL6-8
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 3/8in. x 3/8in. Tube OD, 2-Ferrule, Oriffice: 6.4mm, Cv:0.7, Black Knob Handle
Out of stock

Livraison en 10 jours ouvrés.
NGSS-FL2-5
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 1/8in. x 1/8in. Tube OD, 2-Ferrule, Orifice:2mm, Cv:0.09, Black Knob Handle
10 PCE available

Livraison en 3 jours ouvrés.
NGSS-FL4-7
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 1/4in. x 1/4in. Tube OD, 2-Ferrule, Orifice:4mm, Cv:0.35, Black Knob Handle
10 PCE available

Livraison en 3 jours ouvrés.
NGSS-ML6-7
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 6mm x 6mm Tube OD, 2-Ferrule, Orifice:4mm, Cv:0.35, Black Knob Handle
Out of stock

Livraison en 20 jours ouvrés.
NGSS-FNS4-8
Needle Valve, Body: 316SS, MWP: 3,000psig, Packing: PTFE, Conn.: 1/4in. x 1/4in. (F)NPT, Orifice:6.4mm, Cv:0.7, Black Knob Handle
Out of stock

Livraison en 10 jours ouvrés.
NGSS-MS20-8
NGSS-MS20-8
Out of stock

Délai de livraison sur demande (contact).
