3D Series 3-valve Instrumentation Manifolds

3DSS-FL6-CG
3-Valve Manifolds, Body: 316SS, MWP: 6000psig, Packing: Graphite, Inlet: 3/8in. Tube O.D, Outlet: Flange (Coplanar), Vent: Optional,Cv: 0.35, Al T-bar Handles, Config: 2-Isolate, 2-Vent Plug & 1-Equalize, Direct Mounting
Out of stock

Délai de livraison sur demande (contact).
3DSS-FNS8-C
3-Valve Manifolds, Body: 316SS, MWP: 6000psig, Packing: PTFE, Inlet: 1/2in. (F)NPT, Outlet: Flange (Coplanar), Vent: Optional,Cv: 0.35, Al T-bar Handles, Config: 2-Isolate & 1-Equalize, Direct Mounting
Out of stock

Délai de livraison sur demande (contact).
3DSS-FNS8-AG
3-Valve Manifolds, Body: 316SS, MWP: 6000psig, Packing: Graphite, Inlet: 1/2in. (F)NPT, Outlet: Flange,Cv: 0.35, Al T-bar Handles, Config: 2-Isolate & 1-Equalize, Direct Mounting
Out of stock

Délai de livraison sur demande (contact).
3DSS-FL8-L
3-Valve Manifolds, Body: 316SS, MWP: 6000psig, Packing: PTFE, Process/Inlet: 1/2in. Tube O.D, Inst./Outlet: Flange, Vent: Optional,Cv: 0.35, Al T-bar Handles, Config: 2-Isolate, 2-Vent Plugs & 1-Equalize, Direct Mounting
Out of stock

Délai de livraison sur demande (contact).
3DSS-FNS8-L
3-Valve Manifolds, Body: 316SS, MWP: 6000psig, Packing: PTFE, Process/Inlet: 1/2in. (F)NPT, Inst./Outlet: Flange, Vent: Optional,Cv: 0.35, Al T-bar Handles, Config: 2-Isolate, 2-Vent Plugs & 1-Equalize, Direct Mounting
Out of stock

Délai de livraison sur demande (contact).
3DSS-FNS8-A
3-Valve Manifolds, Body: 316SS, MWP: 6000psig, Packing: PTFE, Inlet: 1/2in. (F)NPT, Outlet: Flange,Cv: 0.35, Al T-bar Handles, Config: 2-Isolate & 1-Equalize, Direct Mounting
10 PCE available

Livraison en 3 jours ouvrés.
3DSS-FL8-A
3-Valve Manifolds, Body: 316SS, MWP: 6000psig, Packing: PTFE, Inlet: 1/2in. Tube O.D, Outlet: Flange,Cv: 0.35, Al T-bar Handles,
Out of stock

Délai de livraison sur demande (contact).
